PROJECTION
Brightness:
450 ANSI Lumens (Max.)
Contrast Ratio:
10,000:1 Typical (Full On/Full Off)
Native Resolution:
WXGA (1280 x 800)
Uniformity:
80% Typical (Japan Standard - JBMA)
Projector Lens:
F-Stop: F/2.0, Focal length, f = 14.95mm, Fixed Lens
Lens Offset Ratio: 100%
Throw Ratio: 1.5 (wide and tele)
Projection Distance:
0.97m ~ 2.58m (3.18 ft ~ 8.48 ft)
Diagonal Screen Size: 0.76m ~ 2.03m (30 ~ 80)
Displayable Colors: Up to 1.07 billion
LED Light Source:
Mercury-free LED light source
LED Light Source Lifecycle:
Up to 30,000 hours Normal / Eco-Mode
|
|
|
I/O CONNECTORS
Power:
1x DC power jack
Computer-In:
1x 24-pin universal connector (black) for analog RGB input signal and for supporting audio output
Audio output:
1x 3.5mm stereo mini phone jack
USB:
1x USB-A for USB Display, Office Viewer, Multimedia Playback (Video/Audio/Photo), USB memory storage access (USB flash drive/internal memory), for supporting projector, media, and image processor firmware upgrade, or optional wireless functionality (USB wireless dongle sold separately)
Memory Card Input:
1x MicroSD card slot for Office Viewer, multimedia playback (Video/Audio/Photo) or for supporting Media & Image Processors firmware updates
HDMI Input:
1x HDMI 1.3 (HDCP compliant)
|
